1buycart Engine Interface Module Individual Fuse ABS Assembly 24V DC

Giới thiệu 1buycart Engine Interface Module Individual Fuse ABS Assembly 24V DC

✌ large-scale Discount Voucher Code！！Enter a discount code to buy more offers！✍
☚ All ready stock !! ☛=
☜ High quality product ☝
☟ Good packaging ✌
We will arrange 24 hours shipping asap！Fast delivery (from China) 5 to 12 business days after shipment(except some special holidays).
♔ ♕ ♖ ☻
Feature:
1. Main Application: This engine interface module is an engine mounted sealed module that provides switching relays for the starter motor solenoids, glow plugs, and fuel solenoids.
2. Individual Fuse: Each of these circuits is protected by a separate fuse installed in the module to ensure safety during operation.
3. ABS Material: Made of premium ABS material, this engine interface module is strong and sturdy, flame retardant and high temperature resistant, ensuring a long life span.
4. Easy Carrying: The engine interface module are convenient for you to store and carry, you can take it easily to help with your work.
5. Ideal Replacement: This engine interface module possesses both professional performance and easy installation, is an ideal replacement for the old and damaged parts.
Specification:
Item Type: Engine Interface Module
Number: 630 466
Mode: EIM PLUS859767
Material: Flame retardant and high temperature resistant ABS
Product Voltage: 24V DC
Product Features:
The engine interface module is a sealed module installed on the engine, which provides switching relays for the starting motor solenoid valve, glow plug and fuel solenoid valve. Each of these circuits is protected by a separate fuse installed in the module. When each circuit is energized, a single LED illuminates.
EIM Plus: The ElIM Plus is used with a control panel that is not equipped with an overspeed shutdown.
Overspeed signal (EIM Plus only) The ElM Plus monitors the speed signal from the magnetic sensor. If the engine speed rises above a preset value, the module sends a 0 volt signal to the generator set control panel to activate the overspeed fault circuit.
Overspeed setpoints are factory set to 55 Hz (50 Hz units) and 66 Hz (60 Hz units). This can be adjusted using the adjustment screw that is accessed through the hole next to the overspeed setting LED. When the engine is running at rated speed (1500 rpm at 50 Hz and 1800 rpm at 60 Hz), adjust the adjusting screw until the overspeed setting LED just goes out. This sets the overspeed value to 10% above the generator set operating speed.
Package List:
1 x
Engine Interface Module
How to Use
Install and use!
