Giới thiệu 1buycart Power Display Module Programmable Voltage Remaining Percentage DC7‑80V
✌ large-scale Discount Voucher Code！！Enter a discount code to buy more offers！✍☚ All ready stock !! ☛=
☜ High quality product ☝
☟ Good packaging ✌
We will arrange 24 hours shipping asap！Fast delivery (from China) 5 to 12 business days after shipment(except some special holidays).
♔ ♕ ♖ ☻
Feature:
1. Function Introduction: The power display module can measure the corresponding parameters according to the actual situation and current voltage and battery capacity percentage.
2. Low Voltage Alarm: The power display module has a low voltage alarm and is adjusting, a programmable battery capacity monitor.
3. Automatic Shutdown: The power display module has automatic shutdown and discharge protection to extend battery life.
4. Support Battery: The power display module supports lithium batteries, acid batteries, lithium iron phosphate batteries, and can also be used for other types of batteries and power supplies, and can also support multiple batteries in series.
5. Widely Used: The power display module is widely used in applications such as automobiles, mobile devices, boats, and outdoor equipment.
Specification:
Item Type: Power Display Module
Material: ABS
Model: XH M241
Working Voltage: DC7V-80V
Working Current: 15mA
Control Accuracy: 0.1V
Working Humidity: 20%-85%RH
Output Voltage: Equal To The Input Voltage
Scope Of Application: Lithium, Acid, Lithium Iron Phosphate Batteries, Adapters, Etc.
Package List:
1 x Power Display Module
Note:
Pay attention to safety.
How to Use
1. Press and hold the stop button to select the desired level. Start button + or Stop button ‑.
2. After selecting the desired voltage. Press the start button, the LED lights up, the relay works, and the voltage is output!
3. When the input voltage is lower than the stop voltage, the relay stops working, the LED goes out and no voltage is output!
4. When the output load is too high and the voltage is not enough to start the load, you can press the start button to force the start!
