_______________❀Product Information❀______________


1. High Security: The learning code of the has a high level of security because of its low repetition rate and re learning mode.
2. Prevent Loss: When the is lost, it can delete the old code and relearn the new code, so you can control it at any time.
3. Flexible: Stable and reliable performance, high receiving sensitivity. Equipped with 1 , it is more flexible to use.
4. Easy to Use: The relay is very easy to set up, learn, relearn and control, and it is easy to use.
5. Widely Used: Mainly used in lighting, electric doors and windows, lifting equipment, gates, elevators, industrial control and security industries, etc.

Specification:
Item Type:  Relay
Material: PCB+ABS
Receiver Parameters
1. Standby Current: 7-9mA
2. Working Current: 70-13mA
3. Relay Specifications: 20A
Parameters:
1. Transmitting Distance: Approx. 10-50m/32.8-164.0ft
2. Built In In the : 2 x CR2016 (75mAh)

How to Use:
Learning  control and clear code:
Learning: Press the learning button once, the receiver LED light is on, press the  control, the LED flashes, and then the  control, the LED light flashes again and then goes out, the learning is complete.
How to adjust the working method:
Interlock: Press and hold the learning button until the LED light flashes, interlocking working mode.
Jog: Press and hold the learning button until the LED light flashes twice, and the work mode is jog.
Self locking: press and hold the learning button until the LED light flashes three times, self locking working mode.
Delay 5 seconds: Press and hold the learning button until the LED light flashes four times, and the work mode is delayed for 5 seconds.
Delay for 30 seconds: Press and hold the learning button until the LED light flashes five times, and the work mode is delayed for 30 seconds.
Delay for 60 seconds: Press and hold the learning button until the LED light flashes six times, and the work mode is delayed for 60 seconds.
Clear code: Press and hold the learning button until the LED light flashes seven times, no longer flashing, the clear code is successful, all the  control will be out of function.

Package List:
1 x Relay
1 x
1 x Plastic Box
