Đầu Nối Tay Thắng Xe Đạp An3 Sang M10X1.0 Bằng Thép Không Gỉ

Giới thiệu Đầu Nối Tay Thắng Xe Đạp An3 Sang M10X1.0 Bằng Thép Không Gỉ

AN -3 Hose to M10x1.0 Concave Female Straight Locator Hose Fitting With Circlip Groove

Type: Hose Ends
Female Concave M10x1.0 Seat
17mm Hex
15mm diameter under the hex
13mm diameter clip locator slot.

Part Number: TORQ-000T3SSM10x1.0LF
Fitting Style: Compression Swivel
Hose End Size: -3 AN ( AN-3)
Adapter Size: M10x1.0
Adapter Attachment: Female threads
Fitting Angle: Straight
Fitting Finish: Brushed
Fitting Material: Stainless steel

The reusable hose ends are easier to install than cutter-style fittings and more user-friendly. With their compression-style design, they can be reused without damaging the fitting, and the nipple pilot prevents damage to the inner tube. Replacement / spare olives are also available.
The hose fittings mechanically clamp onto the hose core to provide the maximum seal possble and separately clamp the stainless steel outerbraid to achieve the strongest possible hose retention.
Their one-piece design allows for improved flow and eliminates two potential leak points (brazed joints).
Manufactured using stainless steel that meet or exceed minimum requirements for aerospace hose fittings. Each component is precision-machined to exact tolerances for trouble-free performance.
Stainless steel retention pins allow 360 degrees of adjustment after installation.

Applications when used in conjuction with the AN-3 PTFE Hose:
Brake Lines, Clutch Lines, Fuel Systems, Turbo oil feed Hose, Coolant Systems, Oil Pressure Systems, Gauge lines & Power Steering. Compatibility: Brake Fluids, Unleaded Petrol, Methanol, Water, & Oil. Ideal for use with Unleaded fuel

Package Include：
1X Female Straight Locator Hose Fitting
