Động cơ Servo 7.5g dành cho máy bay Wltoys V950 điều khiển từ xa

Giới thiệu Động cơ Servo 7.5g dành cho máy bay Wltoys V950 điều khiển từ xa

Features:
1.Light weight and high torque: small size and 7.5g light weight, but the torque could be 1.2kg-cm during 6V input voltage.
2.High Speed: 0.1sec/60° during 4.8V voltage and 0.09 sec/60° during 6V input voltage.
3.Suitable for Wltoys V950 RC helicopter.
4.High quality and durable, equipped with plastic gear, accuracy and not easy to be planished.
5.Easy to install, save your time and extend the lifetime of your helicopter.

Description:
1.This 7.5g servo is suitable for rc helicopter such as Wltoys V950.
2.It reacts very quickly and support 4.8~6.0V input voltage.

Specifications:
Suitable for: WLtoys V950 RC Helicopter
Amplifier type: Analog controller
Operating travel: 90°± 10°
Dead band width: 3μs
Operating speed(at no load)(4.8V): 0.1±0.01sec/60°
Operating speed(at no load)(6V): 0.09±0.01sec/60°
Running current(at no load)(4.8V): 120±30mA
Running current(at no load)(6V): 140±30mA
Stall torque(4.8V): 1.0±0.1kg-cm
Stall torque(6V): 1.2±0.1kg-cm
Stall current(4.8V): 800±50mA
Stall current(6V): 950±50mA
Idle current(4.8V): 6±1mA
Idle current(6V): 6±1mA
Running life(at no load)(4.8V): >10000
Running life(at no load)(6V): >8000
Operation temperature range: -10°C~50°C
Dimensions: 290 * 110 * 270mm
Connector wire length: about 160mm
Weight: 7.5g

Package information:
Package size: 10 * 6.5 * 2cm / 3.9 * 2.6 * 0.79in
Package weight: 12g / 0.44oz
Poly bag package

Package list:
1 x 7.5g Plastic Servo
1 x Servo Arm
