Mô Đun Điều Khiển Nhiệt Độ Thông Minh Beatm Xh-W1209

Giới thiệu Mô Đun Điều Khiển Nhiệt Độ Thông Minh Beatm Xh-W1209

Specifications:
Portable and lightweight, easy to install and use.
Digital display, and its temperature control performance and precision are outstanding.
Can be directly installed in the panel of industrial control equipment, convenient and practical.

Item Name: Temperature Controller Module
Material: PCB
Input Voltage: DC 12V
Temperature Control Range: -50 Degree Celsius - 110 Degree Celsius
Measurement Input: NTC (10K 5%), Water-Resistant Sensor
Measurement Accuracy: 0.1 Degree Celsius
Input Range: 1 Way 10A Relay
Refresh Rate: 0.5 Seconds
Return Difference Accuracy: 0.1 Degree Celsius
Environmental Requirement: -10 Degree Celsius - 60 Degree Celsius, Humidity: 20% - 85%
Overall Power Consumption: State Current: ≤35mA, Pick-up Current: ≤65mA
Display: 0.28inch Three Digital Tubes
Temperature Protection: 0 Degree Celsius - 110 Degree Celsius
Resolution: 19.9 to 99.9: 0.1 Degree Celsius (Others: 1 Degree Celsius)
Features: High Precision, Digital Display, Portable, Easy to Install
Length: 48.5mm/1.91" (Approx.)
Width: 40.1mm/1.58" (Approx.)
Thickness: 15.8mm/0.62 (Approx.)

Notes:
Due to the light and screen setting difference, the items color may be slightly different from the pictures.
Please allow slight dimension difference due to different manual measurement.

Package Includes:
1 x Temperature Controller Module
1 x Cable
