Mô đun sạc nhanh XY-PDS100 QC4.0 QC3.0 Type-C 100W cho điện thoại

Giới thiệu Mô đun sạc nhanh XY-PDS100 QC4.0 QC3.0 Type-C 100W cho điện thoại

#XY-PDS100 #QC4.0 #QC3.0 #Type-C #100W #Step #Down #Mobile #Phone #Quick #Charger #Module #for #Hua-wei #SCP/FCP
XY-PDS100 QC4.0 QC3.0 Type-C 100W Step Down Mobile Phone Quick Charger Module for Hua-wei SCP/FCP for App-le
Description:
100% brand new and high quality
Feature:
The maximum voltage of this product is 32 volts, it is recommended to use within 28 volts! This module is a pure step-down module without boost function. If you want to use 20V output, you must use a DC power supply of more than 21V; the product low voltage can reach 6V, but most of the fast charge will not be activated at 6V; 100W output power Can be reached at PD output (PD20V, 5A).
For low voltage and high current fast charging, please use the original data cable. If you want to measure the charging voltage and current, you must use a low internal resistance USB meter! Otherwise it will affect the charging current!
USB port is required for OPPO and for OnePlus charging!
QC4 + / QC4.0 / PD3.0 and other protocols have to use TYPE_C port!
When the USB port and TYPE_C port are plugged in at the same time, both ports are 5V output！

High compatibility: support the following fast charging protocols:
PD2.0 PD3.0 PPS
for Qualcomm QC4+/QC3.0
for Hua-wei SCP/FCP
for OPPO VOOC
for OnePlus DASH
for App-le 2.4A
for Sam-sung AFC
for VIVO 9V2A Twin engine
for MediaTek PE2.0

Specifications:
Item Type: Quick Charge Module
Material: electronic components
Size: 53x46x21mm/2.08x1.8x0.8in
Color: Black
Quantity: 1 PC

Note:
Transition: 1cm=10mm=0.39inch
Please allow 0-1cm error due to manual measurement. pls make sure you do not mind before you bid.
Due to the difference between different monitors, the picture may not reflect the actual color of the item. Thank you!

Package Includes:
1 x Quick Charge Module
(other accessories demo in the picture are not included!)
