Rơ Le Tự Động Chống Thấm Nước 4pin DC 24V 80A JD1912

Giới thiệu Rơ Le Tự Động Chống Thấm Nước 4pin DC 24V 80A JD1912

Welcome to Oorange.vn

Features:

100% brand new and high quality

With Fuse,more safe,more convenient

Specifications:

High-capacity, 80A switching capability,

1form A.1form B .1formC.2 form A contact arrangement

Application: Auto control device

Size(L*W*H): 28mmx28mmx25mm/1.1inx1.1inx1in

Ambient temperature: -40°C~+125°C

Contact Form: 1a,1b,1c

Contact Capacity : 1a:80A 14VDC

1b:60A 14VDC

1c:80A/60A 14VDC

Coil Voltage: 12VDC/24VDC/48VDC

Coil Power: 1.8W

Contact Resistance: ≤50mΩ

Initial insulation resistance: ≥1,00MΩ

Life: Electrical Life 100,000ops

Mechanical Life 1,000,000ops

Dielectric strength Between off-contact: 500VAC

Between Coil contact : 500VAC

Installing form: Tri-clamp connection, socket mount

Environment Temperature: -40°C~+125°C

Package Including:

1 x Relay

Note:

1.Please allow 0.1-0.3cm differences due to manual measurement, thanks.

2.Please understand because of the light irradiation or computer display difference, so I can't guarantee photos and real color is 100% the same.

We will ship to you asap
Always need 13-18 business days to ship before delivering because we ship your parcel from oversea
Please wait with patience
Thank you
Have a nice day
