Wireless Decoding Board DC 5V 12V Bluetooth 5.0 MP3 Player Color Screen Module Car Kit USB Radio TF FM With Remote Control

Giới thiệu Wireless Decoding Board DC 5V 12V Bluetooth 5.0 MP3 Player Color Screen Module Car Kit USB Radio TF FM With Remote Control

【Specification】
Infrared receiver module
TF card slot: connect TF memory card (maximum support 32GB, not included);
LED: digital color screen display, showing red;
AUX interface: audio input interface
MIC: support call and recording function;
USB interface: connect U disk (maximum support 32GB, not included);
PREV/VOL-: short press is to select the previous song; long press is to decrease the volume
PLAY/PAUSE: short press is to switch between pause and play; long press is to radio FM automatic station;
NEXT/VOL+: short press is to select the next song; long press is to increase the volume;
MODE: Switch between USB/TF/FM/AUX/BLUETOOTH;

Main control IC: AC6926
Bluetooth IC: AC6926 Bluetooth version is 5.0
Music format: MP3/WMA/WAV/FLAC/APE lossless format
Radio FM frequency: 87.5-107.5 MHZ
Support function introduction: support MP3 / USB / TF / LINE IN / FM / BLUETOOTH / remote control connection / DC 5V or 12V (optional)
About structure: Panel size: 75*50 MM, screw holes around the panel, the depth of the board is 18MM

【Recording function description】
1. Long press the MODE button to start recording, and long press the MODE button again to cancel the recording function;
2. Press the MODE button again to play the recording file;
3. When recording, you need to connect a storage device, such as: U disk or TF card;

【Package included】
1 x MP3 WMA WAV Decoder Board
1 x Remote control (without batteries)
1 x Cables
Note: no retail packing box，but we will pack better before shipping. thanks
